AFMG SysTune

Spec sheet

Purpose

SysTune performs real-time audio measurement and analysis for live sound, installed sound, and industry applications.Read 9 Oct 2026 · afmg.eu

Intended users

AFMG describes Standard as intended for live sound, audio engineering, installed sound, and development professionals, and Pro as suited to laboratory measurements, loudspeaker development, building acoustics, and installed sound.Read 9 Oct 2026 · afmg.eu

Trial

AFMG provides a SysTune Trial Request page, but the opened page does not state a trial duration.Read 9 Oct 2026 · afmg.eu

Integrations

SysTune offers an open plug-in API and lists integrations from manufacturers including d&b audiotechnik, Lake, and Linea Research.Read 9 Oct 2026 · afmg.eu

Support

AFMG's SysTune license terms state that email and telephone technical support are provided for six months after purchase.Read 9 Oct 2026 · afmg.eu

Headquarters

Berlin, GermanyRead 28 Sep 2026 · afmg.eu

Analysis features

It displays impulse response, frequency response, phase response, group delay, and a real-time spectrogram, and calculates RT and STI in real time.Read 9 Oct 2026 · afmg.eu

Hardware requirements

AFMG lists 4 GB or more of RAM, a 1.0 GHz or faster processor, and a sound card or audio interface as requirements or recommendations.Read 9 Oct 2026 · afmg.eu

Measurement channels

SysTune measures on up to eight channels simultaneously, and SysTune Pro adds a channel matrix for measurements using more than eight channels.Read 9 Oct 2026 · afmg.eu

Measurement signals

It supports live sound, sweeps, pink noise, and user-defined signals.Read 9 Oct 2026 · afmg.eu

Measurement technology

AFMG says SysTune uses its patented Real-Time Deconvolution algorithm to measure and process full-length impulse responses in real time.Read 9 Oct 2026 · afmg.eu

Operating system

AFMG lists Windows Vista SP1, Windows 7, Windows 8, Windows 10, and Windows 11 as supported operating systems.Read 9 Oct 2026 · afmg.eu

Remote control

Its browser-based web interface lets users remotely control measurements over Wi-Fi from mobile devices whose browsers support SVG graphics.Read 9 Oct 2026 · afmg.eu

Security and data handling

AFMG's website privacy policy says website data is stored in the EU by hosting providers whose data centers are TÜV-certified to ISO 27001.Read 9 Oct 2026 · afmg.eu

Virtual EQ

Standard simulates high-pass, low-pass, shelving, and four parametric filters, while Pro adds 20 configurable IIR or FIR filters.Read 9 Oct 2026 · afmg.eu
