Model Xtractor

Spec sheet

Purpose

Model Xtractor is a relational database modeling inspection tool for traditional or enhanced ER models, generated models, and diagrams created from scratch.Read 11 Oct 2026 · data-xtractor.com

Audience

The maker presents Model Xtractor as a tool to help users understand relational data models without needing to be an expert.Read 11 Oct 2026 · data-xtractor.com

Security

The maker says Xtractor applications cannot modify remote database data or metadata, while model extensions are saved in the local user database.Read 11 Oct 2026 · data-xtractor.com

Support

The maker describes products other than Data Xtractor as free, provided as-is, and without support.Read 11 Oct 2026 · data-xtractor.com

Credential handling

The maker says saved database passwords are encrypted in its local database and masked in the connection string property.Read 11 Oct 2026 · data-xtractor.com

Database support

The maker lists support for SQLite, Firebird, Microsoft SQL Server CE, Access, MySQL, MariaDB, PostgreSQL, SQL Server, Oracle, IBM Db2, SAP ASE, SAP SQL Anywhere, Snowflake, Redshift, Azure, and Amazon Aurora.Read 11 Oct 2026 · data-xtractor.com

Diagram export

Diagrams can be saved as an image or PDF.Read 11 Oct 2026 · data-xtractor.com

Installation platform

The maker states that all downloads are for Windows.Read 11 Oct 2026 · data-xtractor.com

Local data

By default, user data is stored in the SQLite file Xtractor.db under the user's AppData\Local\Xtractor folder.Read 11 Oct 2026 · data-xtractor.com

Model customization

Users can create virtual custom joins, chains, aliases, and many-to-many connectors without changing the connected database.Read 11 Oct 2026 · data-xtractor.com

Model views

It can customize rich generated models such as Detailed, Structural, and Relationships, as well as simplified Simple, Topological, and Graph models.Read 11 Oct 2026 · data-xtractor.com

Reverse engineering

It extracts information about database tables, views, columns, and relationships in a one-time reverse engineering operation.Read 11 Oct 2026 · data-xtractor.com
