NeoCDRX
github.com
What it is
NeoCDRX is a free homebrew emulator for Neo Geo CD and CDZ games on GameCube, Wii and Wii U through Virtual Wii. It supports region settings for USA, Europe and Japan, which provide different languages and can affect some game content. The listed processor cores are Z80 3.6 and M68000 3.3, and audio controls include a three-band equalizer for music and sound effects. Supported controllers include Wii Remote, Wii Remote Plus, Wii Remote with Nunchuk and GameCube controller. Media options include SD/SDHC, USB and DVD, plus GameCube options WKF and IDE-EXI V1. Virtual memory card saves can go to SD or USB, or to a physical GameCube memory card. Setup requires a Neo Geo CD/CDZ BIOS file named NeoCD.bin in NeoCDRX/bios. Each game goes in its own folder under NeoCDRX/games, with an mp3 subfolder for music. Wii and Wii U Virtual Wii installations are packaged for Homebrew Channel; using the Wii version requires a way to run unsigned code. The README describes the project as GPL open source, while GitHub lists LGPL-2.1.
Spec sheet
- Purpose
- NeoCD RX is a Neo Geo CD/CDZ emulator for GameCube, Wii, and Wii U's Virtual Wii.Read 7 Oct 2026 · github.com
- Product
- NeoCD RX is a Neo Geo CD/CDZ emulator for GameCube, Wii, and Wii U's Virtual Wii.Read 7 Oct 2026 · github.com
- License
- The README describes the project as open source under the GPL license; GitHub lists an LGPL-2.1 license.Read 7 Oct 2026 · github.com
- Maker
- The repository is owned by the GitHub user niuus.Read 7 Oct 2026 · github.com
- Audio
- The emulator includes a three-band sound effects and music equalizer.Read 7 Oct 2026 · github.com
- BIOS requirement
- The emulator requires a Neo Geo CD/CDZ BIOS file named NeoCD.bin in the NeoCDRX/bios directory.Read 7 Oct 2026 · github.com
- Channels
- The README says users can install a NeoCD-RX Forwarder Channel for Wii/vWii or a special NeoCD-RX Channel for Wii U.Read 7 Oct 2026 · github.com
- Controllers
- Supported controllers are Wii Remote, Wii Remote Plus, Wii Remote with Nunchuk, and GameCube controller.Read 7 Oct 2026 · github.com
- Download packaging
- The README says the Wii and Wii U Virtual Wii installation is packaged in Homebrew Channel format and describes a separate NeoCDRX folder for the GameCube port.Read 7 Oct 2026 · github.com
- Game files
- Each game must be placed in its own folder under NeoCDRX/games, with an mp3 subfolder for music tracks.Read 7 Oct 2026 · github.com
- Game setup
- Game data and MP3 music tracks are placed in individually named folders under the NeoCDRX games directory; each folder is treated as a full CD.Read 7 Oct 2026 · github.com
- Homebrew
- The README describes NeoCD RX as a homebrew application that requires a way to run unsigned code on a Nintendo Wii.Read 7 Oct 2026 · github.com
- Installation
- The Wii and Wii U Virtual Wii installation is packaged in Homebrew Channel format, and the README says users need a way to run unsigned code on Wii.Read 7 Oct 2026 · github.com
- Latest release
- The releases page lists v1.0.02, dated 20230403, as the latest release.Read 7 Oct 2026 · github.com
- Lineage
- The project says it is forked from NEO-CD REDUX and credits several earlier NeoCD emulators.Read 7 Oct 2026 · github.com
- Processors
- Features include Z80 emulator core 3.6 and M68000 emulator core 3.3.Read 7 Oct 2026 · github.com
- Region settings
- Users can choose USA, Europe, or Japan regions for access to different languages and, in some cases, altered game content.Read 7 Oct 2026 · github.com
- Release
- The releases page identifies v1.0.02, dated 20230403, as the latest release.Read 7 Oct 2026 · github.com
- Save data
- Neo Geo CD virtual memory card saves can go to SD/USB or a physical GameCube memory card.Read 7 Oct 2026 · github.com
- Save support
- It supports Neo Geo CD virtual memory card saves to SD/USB or a physical GameCube memory card.Read 7 Oct 2026 · github.com
- Storage
- Listed storage options include SD/SDHC, USB, WKF for GameCube, IDE-EXI V1, and DVD.Read 7 Oct 2026 · github.com
- Storage and media
- The emulator supports SD/SDHC, USB, WKF for GameCube, IDE-EXI V1, and DVD.Read 7 Oct 2026 · github.com
Strong points and limits
Strong points
- Supports Neo Geo CD and CDZ games
- Offers four listed controller options
- Saves virtual memory cards to SD, USB or GameCube card
- Includes a three-band audio equalizer
Limits
- Requires a NeoCD.bin BIOS file
- Games need individually arranged folders and music subfolders
- Wii use requires a way to run unsigned code
- GitHub lists an LGPL-2.1 license while README says GPL
Who it suits
NeoCDRX may suit people with GameCube, Wii or Wii U Virtual Wii systems who can run homebrew software and have the required BIOS and game files.
Verdict
NeoCDRX supports several Nintendo systems, storage options and controller types for Neo Geo CD/CDZ emulation. Setup depends on a BIOS file, correctly arranged game folders and a homebrew method.
