What it is

PCSCHEMATIC Automation, also called PC Automation, is Windows CAD software for electrical documentation. It works with components and their relationships, generating bills of materials, cross-references and other required documents as installations are built. Default settings follow current electrical-industry standards for symbols, naming, text and line thickness. Its component portal offers over 60,000 components with images, symbols and descriptions, while the Component Wizard helps users create or customize components for their own database.

Lists can be exported to Excel, XML and text files for use in relevant third-party applications. A COM/OLE Automation interface supports custom functions. The program supports DXF, PDF underlays and offline use. The free version is limited to 10 pages, 25 electrical symbols and 200 connection points, with demo component-portal access. PC Automation 200 costs €1325.00 per year, billed annually, with a 12-month minimum; PC Automation Advanced costs €2280.00 per year on the same billing and minimum, without restrictions on pages, symbols or connections. Subscribers can get technical support by phone or email on weekdays, with remote support available.

Spec sheet

Purpose
PC Automation is a CAD program for electrical documentation that works directly with components and their relationships.Read 9 Oct 2026 · pcschematic.com
Intended users
PC SCHEMATIC describes its CAD software as intended for professionals in automation and electrical installation.Read 9 Oct 2026 · pcschematic.com
Support
Subscribers get technical support by phone or email on weekdays, with remote support also available for technical issues and questions.Read 9 Oct 2026 · pcschematic.com
Headquarters
Roskilde, DenmarkRead 28 Sep 2026 · pcschematic.com
Automatic documentation
The program automatically creates bills of materials, cross-references and necessary documents as installations are built with components.Read 9 Oct 2026 · pcschematic.com
Component portal
The component portal offers over 60,000 up-to-date components with images, symbols and descriptions.Read 9 Oct 2026 · pcschematic.com
Custom components
The Component Wizard guides users through creating or customizing components, which are stored in their own database.Read 9 Oct 2026 · pcschematic.com
Exports and integration
Lists can be exported to Excel, XML and text files, and the vendor says they can be used in relevant third-party applications.Read 9 Oct 2026 · pcschematic.com
Extensibility
PC Automation includes a COM/OLE Automation interface for designing custom functions.Read 9 Oct 2026 · pcschematic.com
Installer
The vendor offers PC Automation 26 as ZIP and EXE downloads and instructs users to run the EXE on a PC.Read 9 Oct 2026 · pcschematic.com
Maker history
PC SCHEMATIC says it was founded in Jyllinge in 1978 as Dansk Prototype Service ApS.Read 9 Oct 2026 · pcschematic.com
Security and compliance
The product page states that PC Automation follows current electrical-industry standards; the official pages reviewed did not state a security certification.Read 9 Oct 2026 · pcschematic.com
Standards
Default settings follow current electrical-industry standards for symbols, naming, texts and line thicknesses.Read 9 Oct 2026 · pcschematic.com

Plans and prices

PC Automation Free Version Free 10 pages · 25 electrical symbols · 200 connection points · full-version features · demo component-portal access Read 9 Oct 2026 · pcschematic.com
PC Automation 200 €1,325 a year Invoiced annually; subscription minimum 12 months; page also shows €110 / month per license. Max. 12 pages per project · max. 200 symbols per project · all functions · component-portal access Read 9 Oct 2026 · pcschematic.com
PC Automation Advanced €2,280 a year Invoiced annually; subscription minimum 12 months; page also shows €190 / month per license. No restrictions on pages, symbols or connections · all functions · full component-portal access Read 9 Oct 2026 · pcschematic.com

Every PCSCHEMATIC Automation plan and price →

Strong points and limits

Strong points

  • Automatically creates bills of materials and cross-references.
  • Portal offers over 60,000 components.
  • Exports lists to Excel, XML and text.
  • Supports offline use, DXF and PDF underlays.

Limits

  • Windows only.
  • Free version limits pages, symbols and connection points.
  • Paid subscriptions require a 12-month minimum.

Who it suits

PC SCHEMATIC describes the software for professionals in automation and electrical installation. It is suited to Windows users who need electrical documentation built around components.

Verdict

PC Automation combines component-based electrical documentation with automatic outputs and a large component portal. The free edition has defined project limits, while paid subscriptions remove those limits at the Advanced tier.
