OpenIPAM

github.com

Free plan Open source WebLinuxAPISelf-hosted
Visit github.com
Spec score 8.4 #4 of 18 in Ipam Tool

What it is

OpenIPAM is a free, open-source IP address management and CMDB tool for network and infrastructure inventory. It manages CIDR subnets, IP assignments and reservations, duplicate-IP conflicts, VLANs, IP ranges, and subnet calculations. DHCP tracking covers scopes, leases, reservations, options, and utilization. Its inventory supports 14 host types, hardware lifecycle tracking, locations and racks, maintenance windows, and company records. It can run in a browser with local storage or use an optional Python Flask backend with server-side SQLite for multi-user access. Server mode adds SAML 2.0 single sign-on with Microsoft Entra ID, authenticated routes, and a REST API for entity management, cross-entity search, dashboard statistics, and JSON backup or import. The project describes signed session cookies with an eight-hour lifetime and user-attributed audit entries. CSV host import and JSON backup and restore, including DHCP data, are supported. Browser-mode data stays in the browser; server-mode data is stored in the server-side SQLite file. The plan costs nothing. Current browser support covers Chrome, Firefox, Safari, and Edge, with WebAssembly and ES6+ required.

Spec sheet

What it does
OpenIPAM is an open-source browser-based IP address management and configuration management database tool.Read 15 Oct 2026 · github.com
Purpose
OpenIPAM is an open-source IP address management and CMDB tool for managing network and infrastructure inventory.Read 7 Oct 2026 · github.com
Intended users
The README names homelabs, small businesses, network engineers, and IT departments as intended users.Read 7 Oct 2026 · github.com
Deployment
The browser version can be opened from downloaded files, and the repository includes a Linux setup script for its optional backend.Read 7 Oct 2026 · github.com
API
Server mode provides a REST API with CRUD endpoints for entities, cross-entity search, dashboard statistics, and JSON backup or import.Read 7 Oct 2026 · github.com
API authentication
The server code allows health and authentication routes without a session and gates other API routes behind login and role checks.Read 15 Oct 2026 · github.com
Audit history
Create, update, and delete operations are logged with old and new values, and IP assignment history is retained.Read 15 Oct 2026 · github.com
Authentication
Server mode supports SAML 2.0 single sign-on with Microsoft Entra ID and requires authentication for routes.Read 7 Oct 2026 · github.com
Backups and import
It supports CSV host import and JSON database backup and restore, including DHCP data.Read 7 Oct 2026 · github.com
Browser requirements
Supported browsers are the latest two versions of Chrome, Firefox, Safari, and Edge with WebAssembly and ES6 support.Read 15 Oct 2026 · github.com
Browser support
The project lists current two-version support for Chrome, Firefox, Safari, and Edge and requires WebAssembly and ES6+ support.Read 7 Oct 2026 · github.com
CMDB
The inventory supports 14 host types, hardware lifecycle tracking, locations and racks, maintenance windows, and company records.Read 7 Oct 2026 · github.com
CMDB host types
The inventory supports 14 host categories such as virtual machines, physical systems, containers, firewalls, routers, switches, databases, and printers.Read 15 Oct 2026 · github.com
Conflict detection
The application flags duplicate addresses, subnet mismatches, and inappropriate network or broadcast addresses.Read 15 Oct 2026 · github.com
Data privacy
The README states that browser-mode data stays in the browser, while server mode stores data in a server-side SQLite file.Read 7 Oct 2026 · github.com
Deployment modes
It can run entirely in a browser or use a Python Flask backend for shared server access.Read 15 Oct 2026 · github.com
DHCP
It tracks DHCP scopes, leases, reservations, options, and utilization.Read 7 Oct 2026 · github.com
DHCP management
DHCP features cover scopes, leases, reservations, options, and visual utilization indicators.Read 15 Oct 2026 · github.com
Hardware lifecycle
Host records can track warranties, end-of-life dates, purchases, vendors, models, and asset tags.Read 15 Oct 2026 · github.com
Import and backup
The product imports and exports host CSV files and supports full JSON backup and restore.Read 15 Oct 2026 · github.com
Installation requirements
Linux setup requires Python 3, pip, a virtual environment, and the xmlsec development library for SAML; macOS setup uses Homebrew for libxmlsec1 and pkg-config.Read 15 Oct 2026 · github.com
IP address management
IP records include assignments, reservations, DNS names, and MAC addresses.Read 15 Oct 2026 · github.com
Issue and pull-request status
GitHub displays zero issues and zero pull requests for the repository.Read 15 Oct 2026 · github.com
Known gaps
The project lists role-based access control, DNS record management, topology visualization, and advanced reporting among areas where contributions are wanted.Read 7 Oct 2026 · github.com
Licence
The repository states that OpenIPAM is distributed under the MIT licence.Read 15 Oct 2026 · github.com
Limit: DNS records
The contribution list identifies forward and reverse DNS record management as an unfinished area.Read 15 Oct 2026 · github.com
Limit: notifications
Stale-IP detection and notification features for warranty expiry or IP exhaustion are listed as areas for contribution.Read 15 Oct 2026 · github.com
Limit: reporting
Advanced reporting, utilization trends, capacity forecasting, and PDF export are listed as requested contributions.Read 15 Oct 2026 · github.com
Limit: topology visualization
The contribution list identifies network topology visualization as an area still needing help.Read 15 Oct 2026 · github.com
Local data storage
Browser mode stores the SQLite database in WebAssembly and IndexedDB, while server mode stores it in SQLite on the server.Read 15 Oct 2026 · github.com
Locations and racks
Location management models datacenters, buildings, rooms, and racks with visual rack positioning.Read 15 Oct 2026 · github.com
Maintenance scheduling
Maintenance windows support eight types, impact levels, recurring schedules, and affected resources.Read 15 Oct 2026 · github.com
Maker account
The DonkeyXBT GitHub account shows three repositories, 65 stars, one follower, and 17 following accounts.Read 15 Oct 2026 · github.com
Microsoft integration
Server mode integrates with Microsoft Entra ID through SAML 2.0 single sign-on and single logout.Read 15 Oct 2026 · github.com
Network management
Features include CIDR subnets, IP assignment and reservations, duplicate-IP conflict detection, VLANs, IP ranges, and a subnet calculator.Read 7 Oct 2026 · github.com
Offline operation
The browser mode is designed to keep working without internet access after initial loading.Read 15 Oct 2026 · github.com
Public API
The backend exposes REST CRUD endpoints for companies, subnets, hosts, IPs, VLANs, ranges, locations, maintenance, templates, DHCP, settings, audit logs, backups, and search.Read 15 Oct 2026 · github.com
Repository activity
The repository's main branch page records an update on March 26, 2026.Read 15 Oct 2026 · github.com
Repository popularity
The repository page shows zero stars and zero forks.Read 15 Oct 2026 · github.com
Repository releases
GitHub currently shows no packaged releases for the repository.Read 15 Oct 2026 · github.com
Route protection
Unauthenticated API requests receive HTTP 401 responses and page requests are redirected to the login page.Read 15 Oct 2026 · github.com
Scale claim
The project says SQLite and IndexedDB can support thousands of hosts and hundreds of megabytes of data.Read 15 Oct 2026 · github.com
Search and productivity
Global search, keyboard shortcuts, context menus, saved filters, bulk edits, dark mode, and column customization are included.Read 15 Oct 2026 · github.com
Security details
The project describes signed session cookies with an 8-hour lifetime, HttpOnly, SameSite=Lax, and user-attributed audit entries.Read 7 Oct 2026 · github.com
Session security
The Flask backend configures HttpOnly, SameSite=Lax cookies with an eight-hour session lifetime.Read 15 Oct 2026 · github.com
Storage modes
It can run in a browser with local storage or use a Python Flask backend with server-side SQLite for multi-user access.Read 7 Oct 2026 · github.com
Subnet management
Subnets support CIDR configuration with gateway, DNS, VLAN, and company associations.Read 15 Oct 2026 · github.com
Technology stack
The project uses vanilla HTML, CSS, and JavaScript, sql.js WebAssembly, IndexedDB, Flask, flask-cors, SQLite, and python3-saml.Read 15 Oct 2026 · github.com
VLAN management
It includes nine VLAN classifications including data, voice, management, DMZ, guest, IoT, storage, backup, and native.Read 15 Oct 2026 · github.com

Plans and prices

Free Free No paid tier required Browser-only or Flask server mode · IPAM/CMDB features · self-hosted deployment Read 15 Oct 2026 · github.com
OpenIPAM Free Open-source · zero cost · browser-only or self-hosted backend Read 7 Oct 2026 · github.com

Every OpenIPAM plan and price →

Strong points and limits

Strong points

  • Tracks IP, VLAN, and DHCP information
  • Inventory supports 14 host types
  • Browser-only and self-hosted deployment options
  • Server mode includes SAML 2.0 and a REST API

Limits

  • Browser mode stores data in the browser
  • Server mode stores data in a SQLite file
  • Role-based access control is a listed contribution gap
  • Requires WebAssembly and ES6+ in the browser

Who it suits

OpenIPAM is aimed at homelabs, small businesses, network engineers, and IT departments managing address and infrastructure records. Browser-only use fits local storage, while server mode provides multi-user access and an API.

Verdict

OpenIPAM covers address management, DHCP tracking, and infrastructure inventory, with browser and server deployment paths. Check the listed contribution gaps, particularly role-based access control, DNS management, topology visualization, and advanced reporting, against your needs.
