sFlowTrend

inmon.com

Free plan WebWindowsmacOSLinuxAPISelf-hosted
Visit inmon.com
Spec score 8.3 #6 of 33 in Bandwidth Monitoring Software

What it is

sFlowTrend is a graphical tool for monitoring network and server activity, including leading network users and applications in real time. It uses sFlow and extensions to connect network, server, and application performance information. It can help identify bandwidth use, unusual traffic, host CPU and memory utilization, and usage trends for upgrade planning. Monitoring requires switches or hosts that send data using the sFlow standard. The software is written in Java and requires Java 11 or later; available downloads include Windows, Linux installers and packages, and a Docker image. From version 7.0, users connect to an installed server through a web client over HTTP or HTTPS. The free plan supports at most five switches or hosts and stores one hour of data in memory. The license permits one copy and bars commercial use without separate written authorization and applicable fees. It provides the software as-is without warranty. Pricing is available on request for other use.

Spec sheet

What it does
sFlowTrend is a graphical network and server monitor that uses sFlow to show real-time top bandwidth users and applications.Read 15 Oct 2026 · inmon.com
Purpose
sFlowTrend is a free graphical network and server monitoring tool that displays real-time top network users and applications.Read 29 Sep 2026 · inmon.com
Support
Support requests go through the InMon customer portal and users can also use the sFlowTrend Google Group.Read 15 Oct 2026 · inmon.com
Headquarters
San Francisco, California, United StatesRead 28 Sep 2026 · inmon.com
Founded
1999Read 28 Sep 2026 · inmon.com
Maker
InMon describes itself as a developer of traffic monitoring solutions for high-speed switched networks and says it works with leading switch vendors.Read 29 Sep 2026 · inmon.com
Alerts
Thresholds can raise events for abnormal traffic and notifications can be sent by email or syslog.Read 15 Oct 2026 · inmon.com
Architecture
The documented design is a continuously running client/server service with multiple browser clients able to connect to one server.Read 15 Oct 2026 · inmon.com
Bandwidth analysis
Built-in views help identify users, applications and abnormal traffic consuming network bandwidth.Read 15 Oct 2026 · inmon.com
Company founding
LinkedIn lists InMon Corp. as founded in 1999.Read 15 Oct 2026 · linkedin.com
Company headquarters
LinkedIn lists headquarters in San Francisco, California, at 1 Sansome Street, 35th Floor.Read 15 Oct 2026 · linkedin.com
Company location
InMon Corp. lists its address as 1 Sansome Street, 14th Floor, San Francisco, California 94104.Read 29 Sep 2026 · inmon.com
Company size
LinkedIn lists InMon Corp. as a privately held software-development company with 2–10 employees.Read 15 Oct 2026 · linkedin.com
Current version
The downloadable sFlowTrend release is version 8.0.0.Read 15 Oct 2026 · inmon.com
Developer ecosystem
sFlow.org publishes specifications, example code, agent source code, test scripts and the sFlow Toolkit for developers.Read 15 Oct 2026 · sflow.org
Docker deployment
A Docker image is provided for sFlowTrend.Read 15 Oct 2026 · inmon.com
Documentation depth
The online manual covers installation, dashboards, network, hosts, services, thresholds, events, reports, filtering, configuration, troubleshooting, REST API and database fields.Read 15 Oct 2026 · inmon.com
Downloads
InMon lists Windows, 64-bit Windows with bundled 64-bit JRE, Linux installer, Linux RPM and Debian packages.Read 15 Oct 2026 · inmon.com
Free-edition retention
The free edition keeps one hour of collected data in memory.Read 15 Oct 2026 · inmon.com
Free-edition scale
The free edition accepts sFlow from at most five switches or hosts.Read 15 Oct 2026 · inmon.com
Host metrics
Host performance metrics include CPU and memory utilization.Read 15 Oct 2026 · inmon.com
HTTP monitoring
The product's service views include HTTP performance data such as virtual hosts, URIs and user agents.Read 15 Oct 2026 · inmon.com
Independent deployment example
Open vSwitch documentation identifies sFlowTrend as a cross-platform Java collector and uses UDP port 6343 in its setup example.Read 15 Oct 2026 · ovs-istokes.readthedocs.io
Independent feature confirmation
FlowNetSecure describes monitoring of virtual and physical server CPU, memory, disk I/O, network I/O, switch flows and application metrics through sFlow collectors.Read 15 Oct 2026 · flownetsecure.com
Independent limit confirmation
FlowNetSecure characterizes the free edition as limited to roughly five agents and one hour of retention, recommending Pro for tens of agents and longer analysis.Read 15 Oct 2026 · flownetsecure.com
Independent platform coverage
FlowNetSecure lists Host sFlow support across AIX, FreeBSD, Linux, Solaris and Windows plus Docker and several hypervisors.Read 15 Oct 2026 · flownetsecure.com
Independent praise
A university study found the tool simple to use for real-time analysis and said its filters became practical after some training.Read 15 Oct 2026 · postgrado.info.unlp.edu.ar
Licence status
An independent university evaluation describes sFlowTrend as free but proprietary rather than open source.Read 15 Oct 2026 · postgrado.info.unlp.edu.ar
License limits
The license grants a non-exclusive, non-transferable right to use one copy and prohibits commercial use without separate written authorization and applicable fees.Read 29 Sep 2026 · inmon.com
Limit: anomaly analysis
The same study reported that finding anomalies was difficult, despite useful instantaneous network visibility.Read 15 Oct 2026 · postgrado.info.unlp.edu.ar
Limit: low-volume connections
The study noted that networks with many low-traffic connections were difficult to analyze with the tool's top-connection view.Read 15 Oct 2026 · postgrado.info.unlp.edu.ar
Monitoring data
It uses sFlow and sFlow extensions to connect network, server, and application performance in an end-to-end view.Read 29 Sep 2026 · inmon.com
Notable news
InMon's home page lists a February 4, 2026 NANOG 96 presentation about monitoring RoCEv2 with sFlow.Read 15 Oct 2026 · inmon.com
Platform requirement
The software is written in Java, runs on most platforms, and requires Java 11 or later.Read 29 Sep 2026 · inmon.com
Protocol requirement
sFlowTrend monitors switches or hosts that send data using the sFlow standard.Read 29 Sep 2026 · inmon.com
Protocols
Switch communication supports SNMP v2c and SNMP v3, while collected telemetry is sFlow.Read 15 Oct 2026 · inmon.com
REST API
The documentation includes a REST API section; the older comparison states REST API support is a Pro-only feature.Read 15 Oct 2026 · inmon.com
Runtime requirement
The current free release requires Java 17 or newer.Read 15 Oct 2026 · inmon.com
Security controls
Optional password authentication restricts access, with administrator-only functions such as adding switches.Read 15 Oct 2026 · inmon.com
Self-hosting
The server is installed locally, starts as a service, stores its database and logs on the host, and can be accessed remotely by browser.Read 15 Oct 2026 · inmon.com
Server monitoring
The tool uses sFlow extensions to connect network, physical-server and virtual-server performance views.Read 15 Oct 2026 · inmon.com
sFlow licensing
The sFlow protocol and related patent rights are licensed royalty-free by InMon for interoperable implementations.Read 15 Oct 2026 · sflow.org
Transport security
The browser client can connect over HTTPS on port 8443.Read 15 Oct 2026 · inmon.com
Trend reporting
The product provides management reports on current and historical performance.Read 15 Oct 2026 · inmon.com
Use cases
The product can help identify bandwidth use, abnormal traffic, host CPU and memory utilization, and usage trends for upgrade planning.Read 29 Sep 2026 · inmon.com
Warranty
The license says the free software is provided as-is without warranty.Read 29 Sep 2026 · inmon.com
Web access
From version 7.0, users connect to the installed server through a web client at localhost port 8087 over HTTP or port 8443 over HTTPS.Read 29 Sep 2026 · inmon.com
Web client
From version 7.0 the Java client was removed and users connect through a browser at HTTP port 8087 or HTTPS port 8443.Read 15 Oct 2026 · inmon.com

Plans and prices

sFlowTrend Free At most five switches or hosts · stores one hour of data in memory Read 29 Sep 2026 · inmon.com
sFlowTrend Free Free free download maximum five switches or hosts · one hour of data in memory Read 15 Oct 2026 · inmon.com
sFlowTrend-Pro Priced on request purchase through InMon customer portal unlimited switches or hosts · persistent historical storage · commercial license Read 15 Oct 2026 · inmon.com

Every sFlowTrend plan and price →

Strong points and limits

Strong points

  • Shows leading users and applications in real time
  • Monitors application and user activity
  • Downloads include Windows, Linux, and Docker
  • Free plan is available

Limits

  • Requires sFlow data from switches or hosts
  • Free plan is limited to five devices
  • Free plan stores one hour of data
  • Commercial use requires written authorization and fees

Who it suits

sFlowTrend suits users monitoring sFlow-enabled switches or hosts who need visibility into network, server, and application activity. Its free plan may fit small monitoring setups of up to five devices.

Verdict

sFlowTrend offers network and server monitoring with a free plan, but the device limit and one-hour memory window are important constraints. Commercial use requires separate authorization and fees, and other pricing is available on request.
