sip-exporter

github.com

Free plan LinuxSelf-hosted
Visit github.com
Spec score 7.9 #7 of 21 in VoIP Monitoring Software

What it is

sip-exporter is a free, open-source Linux and self-hosted eBPF sensor for SIP and correlated RTP monitoring. It exposes Prometheus metrics at /metrics, including SIP traffic, active sessions, RFC 6076 performance, voice quality, RTP, RTCP, fraud, and diagnostic measures. RTP analysis covers jitter, packet loss, packet-delay variation, and E-model MOS; RTCP sender and receiver statistics include loss, jitter, and round-trip time linked by SSRC. Documented fraud indicators include registration scans, INVITE bursts, account takeover after a registration country change, and False Answer Supervision. A Grafana dashboard has 11 sections, with Prometheus alert examples and Alertmanager examples for Slack, PagerDuty, and email. Metrics are documented for Prometheus, VictoriaMetrics, Grafana Cloud, and compatible scrapers. Deployment uses a single container that must run privileged with host networking. Capture is limited to IPv4/UDP SIP and related RTP/RTCP, and the sensor must see signaling and media on the same call path.

Spec sheet

Purpose
sip-exporter is an open-source eBPF sensor that turns SIP signaling and correlated RTP traffic observed on a Linux host into Prometheus metrics and Grafana dashboards.Read 5 Oct 2026 · github.com
Deployment
The project provides a single-container deployment and says the container must run privileged with host networking to access eBPF and the network interface.Read 5 Oct 2026 · github.com
Integrations
The Prometheus-format metrics are documented as compatible with Prometheus, VictoriaMetrics, Grafana Cloud, and other Prometheus-compatible scrapers.Read 5 Oct 2026 · github.com
Privacy
The README says the exporter does not store packets or audio and parses only the fixed 12-byte RTP header, while RTP snapshots copied to userspace may include a small payload prefix.Read 5 Oct 2026 · github.com
Support
The project directs users to GitHub Issues for support, bug reports, and feature requests, and to its security policy for private vulnerability reports.Read 5 Oct 2026 · github.com
License
The project is licensed under AGPL-3.0 and says modified network-accessible versions must offer users the corresponding source under the license terms.Read 5 Oct 2026 · github.com
Capture
It captures IPv4/UDP SIP and correlated RTP/RTCP; SIP over TCP or TLS is not captured.Read 5 Oct 2026 · github.com
Capture method
An eBPF socket filter selects IPv4 SIP packets over UDP for userspace processing; SIP over TCP or TLS is not captured.Read 5 Oct 2026 · github.com
Dashboard and alerts
The repository includes a Grafana dashboard and documented Prometheus alert-rule examples, with Alertmanager examples for Slack, PagerDuty, and email.Read 5 Oct 2026 · github.com
Data handling
The project says it does not store packets or audio; its RTP processing parses the fixed RTP header and does not inspect or persist audio.Read 5 Oct 2026 · github.com
Fraud signals
Documented fraud signals include registration scans, INVITE bursts, account takeover after a registration country change, and False Answer Supervision.Read 5 Oct 2026 · github.com
Grafana dashboard
The repository includes a Grafana dashboard with 11 sections and documented Prometheus alert-rule examples.Read 5 Oct 2026 · github.com
Limits
The sensor requires a host that sees IPv4/UDP SIP signaling and the correlated RTP/RTCP path; IPv6, fragmented UDP, SIP over TCP/TLS, and mirrored traffic for trustworthy QoE/direction are unsupported.Read 5 Oct 2026 · github.com
Metrics
It exposes SIP traffic, active-session, RFC 6076 performance, RFC 6035 voice-quality, RTP, RTCP, fraud, and diagnostic metrics at `/metrics`.Read 5 Oct 2026 · github.com
Network placement
For full metrics, the sensor must run on a host that sees both SIP signaling and RTP media on the same call path.Read 5 Oct 2026 · github.com
RTCP support
It reports RTCP receiver and sender statistics, including loss, jitter, and round-trip time, correlated by SSRC.Read 5 Oct 2026 · github.com
RTP quality
RTP analysis includes jitter, packet loss, packet-delay variation, and E-model MOS for streams correlated with SIP dialogs.Read 5 Oct 2026 · github.com
SIP and RTP metrics
The exporter reports SIP traffic and session metrics, RFC 6076 performance metrics, and RTP quality metrics including packet loss, jitter, and MOS.Read 5 Oct 2026 · github.com
Supported traffic
Capture support is IPv4/UDP SIP and RTP/RTCP; SIP over TCP/TLS, IPv6 traffic, and fragmented UDP are listed as unsupported.Read 5 Oct 2026 · github.com
Telemetry
Anonymous usage telemetry is enabled by default and can be opted out of by setting SIP_EXPORTER_TELEMETRY to false.Read 5 Oct 2026 · github.com

Plans and prices

AGPL-3.0 open-source Free Free for personal and educational use; free for commercial use with conditions under AGPL-3.0 Read 5 Oct 2026 · github.com

Every sip-exporter plan and price →

Strong points and limits

Strong points

  • Open-source AGPL-3.0 licensing
  • Reports jitter, packet loss, and MOS
  • Includes Grafana dashboard and alert examples
  • Documents Prometheus-compatible integrations
  • Does not store packets or audio

Limits

  • SIP over TCP or TLS is unsupported
  • IPv6 and fragmented UDP are unsupported
  • Requires privileged container and host networking
  • Needs signaling and media on the same path

Who it suits

sip-exporter suits Linux operators who can place a privileged sensor where both SIP signaling and RTP media are visible. It fits users already using Prometheus or Grafana-compatible monitoring.

Verdict

sip-exporter provides detailed SIP, RTP, RTCP, quality, and fraud metrics for compatible Linux traffic. Its value depends on meeting strict capture and network-placement requirements.
